Technical
Specifications :
|
|
|
Features :
|
|
230V /
50Hz
|
- Electrical - |
110V / 60Hz |
|
|
|
|
|
- Cooling power: 9000 BTU |
|
| |
|
|
|
|
|
|
|
|
| |
|
|
|
|
-
Refrigerant: R410A filled in 400
g |
|
|
|
|
| |
|
|
|
|
- Room size:
22
㎡
or 240 square feet |
|
|
|
- Cooling capacity:
9,000 BTU (2,640W)
Air Volume 320 M3 /H |
|
| |
|
|
|
|
|
|
|
- Heating capacity:
9,000 BTU(2,640W) Air Volume
510 M3 /H |
|
| |
|
|
|
|
- Dehumidification:
50 Liters/day |
|
|
|
|
- Auto Louver setting at 80
degree sweeping |
|
| |
|
|
|
|
- Capacity of water tank: 4.1
liters |
|
|
|
|
| |
|
|
|
|
- Compressor type:
44A203A |
|
|
|
|
- Two wind speeds “L” & “H” |
|
| |
|
|
|
- Noise level: Heating and
Cooling
Below 56dB
Below 56dB |
|
|
|
- Timer setting: 1H/2H/4H/8H |
| |
|
|
|
|
-
Safety approved: GS / CE / RoHS |
|
|
- Auto Louver setting at 80
degree sweeping |
| |
|
|
|
|
-
Product dimension : 405 (L) x
347 (W) x 762 (H) mm |
|
|
|
| |
|
|
|
|
-
Package dimension : 635 (L) x
405 (W) x 786 (H) mm |
|
|
|
| |
|
|
|
|
- Net weight:
35.5 kgs |
|
|
|
| |
|
|
|
|
- Goss weight:
38.0 kgs |
|
|
|
|
|
|
|
|
|
-
Power consumption heating: 1100W |
|
|
|
|
|
|
|
|
|
-
20’ loaded 153 units/ 40’ loaded
315 units |
|
|
|
